Specifications
Rated Pressure : 10 kPa (0.1 kgf/cm2), 0.1 bar, 1.42 psig
Rated Airflow : 30 L/min, 1.06 cfm
Rated Voltage : 24 V DC
Maximum Pressure : 25 kPa (0.25 kgf/cm2)
0.25 bar
3.56 psig
Current (Mean Value) : 1.7 A or less
Working Pressure Range : 0 to 25 kPa
(0 to 0.25 kgf/cm2)
0 to 0.25 bar
0 to 3.56 psig
Duty Cycle : Continuous
Rated Performance : 10,000 hours
Inlet : -
Outlet : 8.5 mm O.D. straight barb
Coil Insulation Class : Class B equivalent
Mounting Dimensions : 111.7(L) x 125(W) mm
4 - 5/8"(L) x 1 - 59/64"(W)
Weight : 1.9 kg (4.2 Lbs)
Leadwire Length : 300 plus or minus 20 mm (11 - 13/16 plus or minus 25/32")
Control Signal Voltage : 0 to 5 V DC
Application Example
- Anti-decubitus mattresses
- Solder suction devices
